IPark Narrow Parking System

Features

•  Fully Automated Parking System
•  Easy to Install
•  Ideal to install in narrow space like, long garages, etc.
•  Easy to relocate

Car Dimensions

•  Car Length (Max) - 5200 mm
•  Car Width (Max) - 2200 mm
•  Car Height (Max) - 2000 mm
•  Car Weight (Max) - 2300 Kg

Technical Parameters

•  Lifting Motor - 2.2 / 3.7 kW
•  Lifting Speed - 4.0 m/minute
•  Drive - Chain / Wire Rope Drive
•  Operation - Push Button
•  Power Supply - Ac 400 V/50 Hz
•  Three Phase, 5 wire
•  Safety - Photo Electric Sensors
