IPark Pit Puzzle Parking System

Features

  • Semi-Automated Parking System
  •  Easy to Install
  •  Low Maintenance
  •  Modular type, can be relocated in short time

Technical Parameters

  •  Lifting Motor - 2.2 / 3.7 kW
  •  Sliding Motor - 0.37 KW
  •  Lifting Speed - 4.0 m/min
  •  Sliding Speed - 8.0 m/min
  •  Drive - Chain Drive/ Wire Rope Drive
  •  Operation - Touch Screen + Push Button
  •  Power Supply - Ac 400 V / 50 Hz
  •  (Three Phase, 5 wire)
  •  Safety - Photo Electric Sensors

Car Dimensions

  •  Car Length (Max) - 5200 mm
  •  Car Width (Max) - 2200 mm
  •  Car Height (Max) - 2000 mm
  •  Car Weight (Max) - 2300 Kg
